LED-409A

Be the first to review this product

LED-409A - a 40 watt, 15° or 40° beam LED light for the center grill lights on newer JD & CaseIH tractors and more. 3 used for the MX / Magnum, and 6 for the large STX models. John Deere OEM Part Numbers: AL209455. Challenger OEM Part Numbers: 519438D1, 526701D1. CASE / IH OEM Part Numbers: 87539115, 87328621. Will bolt into CIH OEM light housing part #: 87455676, 87455677, 87308895.

Manufacturer: Larsen Lights

LED-409

LED-409A 40° Flood beam

LED-409A - a 40 watt, 40° beam LED light for the center grill lights on newer CaseIH tractors. 3 used for the MX / Magnum, and 6 for the large STX models. Also available as Spot beam. John Deere OEM Part Number: AL209455, Challenger OEM Part Numbers: 519438D1, 526701D1. CASE / IH OEM Part Numbers: 87539115, 87328621. Will bolt into CIH OEM light housing part #: 87455676, 87455677, 87308895.

SKU: LL0072

Availability:

94 in stock

$51.00

Qty:

+ -

LED-409

LED-409A 15° Spot beam.

LED-409A - a 40 watt, 15° beam LED light for the center grill lights on newer CaseIH tractors. 3 used for the MX / Magnum, and 6 for the large STX models. Also available as Flood beam. John Deere OEM Part Numbers: AL209455. Challenger OEM Part Numbers: 519438D1, 526701D1. CASE / IH OEM Part Numbers: 87539115, 87328621. Will bolt into CIH OEM light housing part #: 87455676, 87455677, 87308895.

SKU: LL0317

Availability:

83 in stock

$51.00

Qty:

+ -

Notes:

We are out of the 30 watt PAR-36 light model until around Jan. 20th 2025. You can order the lights, but the order will not ship before late January. All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Overview

LED-409A

If this is ordered for a Challenger tractor, you need to add the adapter cables "Adapter 9005 female to H11 male" (sku: LL0593-wahp) to the order.

LED-409A - a 40 watt led light for the center grill lights on a newer CaseIH Magnum tractor.

Operating Voltage: 10-30V DC
Waterproof rate: IP67
10W x 4 USA CREE LEDs 40 watt
Lumen: 3200
Color: 5000K
Material: aluminum housing
Lens material: Scratch-resistant PC - 15° beam
50000 hours
CE/ROHS

OD: 3 5/16"

LED409, 409, TL6020, spot, TL8630

LED-409A

If this is ordered for a Challenger tractor, you need to add the adapter cables "Adapter 9005 female to H11 male" (sku: LL0593-wahp) to the order.

LED-409A - a 40 watt led light for the center grill lights on a newer CaseIH Magnum tractor.

Operating Voltage: 10-30V DC
Waterproof rate: IP67
10W x 4 USA CREE LEDs 40 watt
Lumen: 3200
Color: 5000K
Material: aluminum housing
Lens material: Scratch-resistant PC - 15° beam
50000 hours
CE/ROHS

OD: 3 5/16"

LED409, 409, TL6020, spot, TL8630

Product tags

spot (10)

Use On Below Models (Click to expand)

Ag-Chem

Sprayer: RG1100B RG1100C RG1300B RG1300C RG700 RG700B RG900B RG900C

Case IH

Sprayer: 2250 Patriot Tier 4B (NA) (10/15 - ) 3240 Patriot Tier 4B (02/14 - ) 3340 Patriot Tier 4B (02/14 - ) 4440 Patriot Tier 4B (08/14 - ) 5550 Trident Tier 4B

Tractor: 170 Puma 170 Puma CVT 180 Magnum Tier 4, Small Frame 185 Puma 185 Puma CVT 190 Magnum Tier 4B, Small Frame 200 Magnum Tier 4B 210 Magnum Tier 4, Small Frame 215 Magnum 215 Puma 215 Puma CVT 220 Magnum Tier 4B 225 Magnum Tier 4B, Small Frame 230 Puma 230 Puma CVT 235 Magnum Tier 4A 240 Magnum Tier 4B 245 Magnum 250 Magnum Tier 4B 255 Magnum 260 Magnum Tier 4A 275 Magnum 280 Magnum Tier 4B 290 Magnum Tier 4A 305 Magnum 310 Magnum Tier 4B 315 Magnum Tier 4A 335 Magnum 340 Magnum Tier 4A 370 Magnum Tier 4A 370 Quadtrac 380 Magnum Tier 4B 420 Quadtrac 450 Quadtrac 470 Quadtrac Tier 4B 500 Quadtrac 540 Quadtrac Tier 4B 550 Quadtrac 580 Quadtrac Tier 4B 600 Quadtrac 620 Quadtrac Tier 4B Magnum 180 Magnum 190 Magnum 200 Magnum 210 Magnum 215 Magnum 220 Magnum 225 Magnum 235 Magnum 240 Magnum 245 Magnum 250 Magnum 260 Magnum 275 Magnum 280 Magnum 290 Magnum 305 Magnum 310 Magnum 315 Magnum 335 Magnum 340 Magnum 370 Magnum 380 MX215 MX245 MX275 MX305

Challenger

Sprayer: 2244

Tractor: MT455D w/Autopower IV MT455D MT455E MT455E w/Autopower IV MT465D MT465D w/Autopower IV MT465E MT465E w/Autopower IV, VI, w/Techstar CVT MT475D w/Techstar CVT MT475D MT475E MT475E w/Autopower IV, VI, w/Techstar CVT MT485D w/Autopower IV, VI, w/Techstar CVT MT485D MT485E MT485E w/Autopower IV, VI, w/Techstar CVT MT495D MT495D w/Autopower VI, w/Techstar CVT MT495E MT495E w/Techstar CVT MT515D MT515D w/Autopower IV, Tier 4 MT515E w/Autopower IV MT515E MT525D MT525D w/Autopower IV, VI, w/Techstar CVT, Tier 4 MT525E w/Autopower IV, VI, w/Techstar CVT MT525E MT535D w/Autopower VI, w/Techstar CVT, Tier 4 MT535D MT535E w/Autopower VI, w/Techstar CVT MT535E MT545D w/Autopower VI, w/Techstar CVT, Tier 4 MT545D MT545E w/Autopower VI, w/Techstar CVT MT545E MT555D MT555D w/Autopower VI, w/Techstar CVT, SISU Engine MT555E w/Autopower VI, w/Techstar CVT MT555E MT565D w/Autopower VI, w/Techstar CVT, SISU Engine MT565D MT565E w/Autopower IV MT565E MT575D MT575D w/Autopower VI, w/Techstar CVT, SISU Engine MT575E w/Autopower VI, w/Techstar CVT MT575E MT585D w/Autopower VI, w/Techstar CVT, SISU Engine MT585D MT585E MT585E w/Autopower VI, w/Techstar CVT MT595E w/Autopower VI, w/Techstar CVT MT595E MT645C MT665C MT675C MT745C MT745D MT755C MT755D MT755E MT765C MT765D MT765E MT775E MT835C MT845C MT845E MT855C MT855E MT865C MT865E MT875C MT875E MT945C MT955C MT955E MT965C MT965E MT975C MT975E

John Deere

Sprayer: 4940 R4023 R4030 R4038 R4040I R4044 R4045 R4050I R4060 R4140I R4150I

Tractor: 6105M 6105R 6110M 6110R 6115M 6115R 6120M 6120R 6125M 6125R 6130M 6130R 6135M 6135R 6140M 6140R 6145M 6145R 6150M 6150R 6150RH 6155M 6155R 6155RH 6170M 6170R 6175M 6175R 6190R 6195M 6195R 6210R 6215R 6230R 6250R 7200R 7210R 7215R 7230R 7250R 7260R 7270R 7280R 7290R 7310R 7R 210 7R 230 7R 250 7R 270 7R 290 7R 310 7R 330 7R 350 8225R 8235R 8245R 8260R 8270R 8285R 8295R 8310R 8310RT 8320R 8320RT 8335R 8335RT 8345R 8345RT 8360R 8360RT 8360T 8370R 8370RT 8400R 9360R 9370R 9410R 9420R 9420RX 9460R 9460RT 9470R 9470RT 9470RX 9510R 9510RT 9520R 9520RT 9520RX 9560R 9560RT 9570R 9570RT 9570RX 9620R 9620RX

New Holland

Combine: CR10.90 CR6.80 CR6.90 CR7.80 CR7.90 CR8.90 CR9.90 CX8.80 CX8.90 FR480 FR550 FR650 FR780 FR850 FR920

Forage Harvester: FR920 A4B FR920 A5

Skid Steer: C227 C232 C234 C237 C238 C245 C327 C332 C334 C337 C338 C345 L213 L215 L216 L218 L220 L221 L223 L225 L228 L230 L234 L313 L315 L316 L318 L320 L321 L323 L325 L328 L330 L334 TV370 TV380

Skid Steer Loader: C227 4/11-9/13 C232 Standard 4/11-12/12, Tier 4A 1/13-12/15, NRC Eff. 1/13, Tier 4B Eff. 3/15 C238 Standard 4/11-12/13, Tier 4A 7/12-4/15, NRC Eff. 7/12 C245 Cab, Tier 4B L213 Standard 4/11-12/13, Tier 4B Eff. 5/13, NRC Eff. 10/13 L215 Standard4/11-12/13, NRC Eff. 10/13 L216 Tier 4B Eff. 5/13 L218 4/11-12/13 L220 4/11-12/13 L223 4/11-12/13 L225 Standard 4/11-12/12, Tier 4A 1/13-12/15, NRC Eff. 1/13 L228 Tier 4B Eff. 3/15 L230 Standard 4/11-12/13, Tier 4A 7/12-4/15, NRC Eff. 7/12

Tractor: T4.105 Tier 4A 12/12-12/14 T4.115 Tier 4A 6/13-12/14 T4.65 Powerstar Eff. 9/11 T4.75 Tier 4A 6/13-12/14, Powerstar T4.85 Tier 4A 12/12-12/14 T4.95 Tier 4A 12/12-12/14 T4020 Standard 4/8-12/14, Deluxe 4/8-12/14 T4030 Standard 4/8-12/14, Deluxe 4/8-12/14 T4040 Standard 12/07-12/14, Deluxe 12/07-12/14 T4050 Standard 12/07-12/14, Deluxe 12/07-12/14 T5.105 Tier 4 Eff. 7/12, Electro Command Tier 4 Eff. 2/13 T5.115 Tier 4 Eff. 7/12, Electro Command Tier 4 Eff. 2/13 T5.95 Tier 4 Eff. 7/12, Electro Command Tier 4 Eff. 2/13 T5040 1/07-12/14 T5050 1/07-12/14 T5060 1/07-12/14 T5070 1/08-12/14 T6.155 Tier 4 T6.165 Tier 4 T6.175 Tier 4 T6010 Delta Tier 3 1/07-3/12, Plus Tier 3 1/7-8/13 T6020 Delta Tier 3 Eff. 1/7, Plus Tier 3 Eff. 1/7, Elite Tier 3 1/7-11/16 T6030 Delta Tier 3 1/7-7/13, Plus Tier 3 1/7-11/13, Elite Tier 3 1/7-9/13 T6040 Elite Tier 3 1/07-11/13 T6050 Delta Tier 3 Eff. 1/7, Plus Tier 3 Eff. 1/7, Elite Tier 3 Eff. 1/7 T6060 Elite Tier 3 1/07-8/16 T6070 Elite Tier 3 Eff. 1/7, Plus Tier 3 Eff. 1/7 T6080 Power & Range Command T7030 Standard 1/7-12/11, Power Command S/N Z9BG07156-Z9BG40124 6/9-12/11 T7040 Standard 1/7-12/11, Power Command S/N Z9BG07719-Z9BG40112 6/9-12/11 T7050 Standard 1/7-12/11, Power Command S/N Z9BG07xxx-Z9BG40114 6/9-12/11 T7060 Standard 1/7-12/11, Power Command S/N Z9BG07xxx-Z9BG40117 6/9-12/11 T8010 T8020 T8030 T8040 T8050 TG210 TG215 TG230 TG245 TG255 TG275 TG285 TG305 TL100A 1/04-12/08 TL80A 1/04-12/08 TL90A 1/04-12/07 TN60DA Deluxe 12/03-12/05 TN60SA Supersteer 12/03-12/08 TN70A Standard 12/03-12/08 TN70DA Deluxe 12/03-12/08 TN70SA Supersteer 12/03-12/07 TN75A Standard 12/03-12/08 TN75DA Deluxe 12/03-12/08 TN75SA Supersteer 12/03-12/08 TN85A 1/04-12/08 TN85DA Deluxe 10/05-12/07 TN85SA Supersteer 10/05-12/07 TN95A 1/04-12/08 TN95DA Deluxe 10/05-12/07 TS100A Standard 7/05-12/07, Delta 7/05-12/07, Plus/Deluxe 7/03-12/07 TS110A Standard 7/5-12/07 TS115A Plus/Deluxe 7/03-12/07 TS125A Plus/Deluxe 7/04-12/07 TS130A TS135A Plus/Deluxe 7/03-12/07 TS6.110 Tier 4B, Models Made in Mexico TS6.120 Tier 4B, Models Made in Mexico TS6.130 Tier 4B, Models Made in Mexico TS6.140 Tier 4B, Models Made in Mexico

Steiger

Tractor: 350 370 Tier 4B 400 420 Tier 4B 450 470 Tier 4B 500 Tier 4B 540 550 580 600 620
