Larsen LED kit for IH 16xx series combines
This kit will replace the 6 lights on the top front cab with complete LED lights. The model we use is the LED-845 and 845-2 with the 50mm easy mount bracket for all the cab lights.
To mount the lights, simply remove the cross bolt that keeps the OEM plastic housing into the "U" clamp, now reuse the "U" clamp for the new light. Use included male spade connectors or splice in the wires, making sure positive is on the correct wire - LED will not work if the polarity is reversed.
The difference between the LED-845 and the LED-845-2 is that the -2 model has a clear lens that allows the light to shine further ahead, opposite the LED-845 that spreads the light faster but have less distance.
We also replaced the auger light, that is the PAR-36 model light (4.5" round sealed beam bulb)
Lights used in this kit can be found in "Related Products".
1620, 1640, 1660, 1670, 1680 and 1682, 1644, 1666 and 1688
The 4 LED-845 Easy mount lights are for the 4 lights hanging from the roof, not all customer's machines are setup the same, so in the picture below the red circled ones are aimed down into the header and you want the LED-845 Easy (SKU LL0414) for those 2, and the blue circled ones are the LED-845-2 easy (SKU LL0415) are aimed out further for more distance light, those are the lights with the clear lens.
The green circled ones are the LED-845 (SKU LL0417)
