Major Overhaul Kit, Perkins 1004.42 Diesel Engine, Standard Pistons

Please supply engine build number before ordering.Includes:• (4) HCPU5LP0058 Piston• (4) HCP4181A045 Piston Ring Set• (1) HCP85042 Rod Bearing Set• (1) HCP81558 Main Bearing Set• (1) HCP3113755161 Thrust Washer Set• (1) HCPU5LT0317 Head Gasket Set• (1) HCPU5LB1171 Conversion Gasket Set• (1) HCP2418F436 Front Crank Seal• (4) HCP3112E011 Piston Pin Bushings• (1) HCP2418F701 Rear Crank Seal• (1) HCM2418F475 Rear Crank Seal• (1) HCP31134132 Cam Bushings• (8) HCP32762144 Connecting Rod Bolts• (8) HCP33221328 Connecting Rod NutsThe HCPBK474 Major Overhaul Kit, Perkins 1004.42 Diesel Engine, Standard Pistons fits equipment brands such as: Case IH, Massey Ferguson

Manufacturer: Hy-Capacity

SKU: HCPBK474

Vendor: Hy-Capacity

Availability:

In stock

$686.84

Qty:

+ -

Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info. Please note that Hy-Capacity items can not be shipped to Canada / International.

Specifications

Products specifications

Attribute name	Attribute value
Engine Manufacturer	Perkins
Engine Notes	Naturally Aspirated
Piston Pin Dia.	1.562"
Engine CID	258
Fuel Type	Diesel
Cylinder Count	4
Bore	4.056"
Stroke Length	5.000"
Rod Journal Dimensions	2.4988" - 2.4996"
Main Journal Dimensions	2.9984" - 2.9992", 2.9984-2.9992"
New/Reman	New
Sold As	Each
Warranty	1 Year
Dimensions	Standard

Products specifications

Attribute name	Attribute value
Engine Manufacturer	Perkins
Engine Notes	Naturally Aspirated
Piston Pin Dia.	1.562"
Engine CID	258
Fuel Type	Diesel
Cylinder Count	4
Bore	4.056"
Stroke Length	5.000"
Rod Journal Dimensions	2.4988" - 2.4996"
Main Journal Dimensions	2.9984" - 2.9992", 2.9984-2.9992"
New/Reman	New
Sold As	Each
Warranty	1 Year
Dimensions	Standard
