11" LuK Dual Stage Clutch Kit, w/ Bearings - New

Multiple clutch options, positively identify before ordering. This is a Safety PTO Clutch, check that the flywheel disc is free after installation. Learn more, Safety PTO Clutch Service Guide.Includes: PPA, 6-Pad Captive Disc, F5176450 (Flywheel Disc), 8301080 (Release Bearing), 836015 (Release Bearing), 836303 (Pilot Bearing) & 836203 (Pilot Bearing)The F5196818NU2 KIT 11" LuK Dual Stage Clutch Kit, w/ Bearings - New fits equipment brands such as: Case IH, New Holland
Manufacturer: Hy-Capacity
SKU: F5196818NU2 KIT
Vendor: Hy-Capacity
In stock
$888.61
+ -
Notes:

All prices are USD. If imported into Canada/Internationally there will be brokerage costs collected by the carrier. Check the"Canada/World" link at the top of the page for more info.  Please note that Hy-Capacity items can not be shipped to Canada / International.

Products specifications
Attribute name Attribute value
Size 11"
Flywheel Step 0.020"
PPA Levers 6
Captive Disc Spec 6 Pad; 1-9/16" 14 Spline Hub; Spring Center
Flywheel Disc Spec 4 Pad; 1" 10 Spline Hub; Solid Center
New/Reman New
Sold As Each
Warranty 1 Year
Products specifications
Attribute name Attribute value
Size 11"
Flywheel Step 0.020"
PPA Levers 6
Captive Disc Spec 6 Pad; 1-9/16" 14 Spline Hub; Spring Center
Flywheel Disc Spec 4 Pad; 1" 10 Spline Hub; Solid Center
New/Reman New
Sold As Each
Warranty 1 Year
Use On Below Models (Click to expand)
Case IH
New Holland
Tractor
T4.100F Yr. 3/16 thru 12/17, w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4.100V Yr. 3/16 thru 12/17, w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4.105V w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4.85F w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4.85V w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4.90F w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4.90LP w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4.90V w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4.95F Mechanical Shuttle T4.95V Mechanical Shuttle T4020 Mechanical Shuttle T4020V Mechanical Shuttle T4030 Mechanical Shuttle T4030F Mechanical Shuttle T4030V Mechanical Shuttle T4040 Mechanical Shuttle T4040F Mechanical Shuttle T4040N Mechanical Shuttle T4040V Mechanical Shuttle T4050 Mechanical Shuttle T4050F Mechanical Shuttle T4050N Mechanical Shuttle T4050V Mechanical Shuttle T4060F w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4060N w/ 4-Pad Flywheel Disc, Mechanical Shuttle T4060V w/ 4-Pad Flywheel Disc, Mechanical Shuttle TN55 Eff. 09/99, Mechanical Shuttle TN60A Eff. 01/03 TN60VA TN65 Eff. 09/99 TN65F w/ 4-Pad Flywheel Disc, Mechanical Shuttle TN65V TN70 Eff. 09/99 TN70A Mechanical Shuttle TN70D Eff. 09/99 TN70NA TN70VA TN75 Eff. 09/99, Mechanical Shuttle TN75A Mechanical Shuttle TN75D Eff. 09/99, Mechanical Shuttle TN75F Mechanical Shuttle TN75V Mechanical Shuttle TN75VA Mechanical Shuttle TN85A Eff. 01/03 TN85DA Eff. 01/03 TN85FA Eff. 01/03 TN85SA Mechanical Shuttle TN90F Eff. 09/97, Orchard Tractor TN95A Eff. 01/03 TN95DA Eff. 01/03 TN95F Eff. 10/01,Orchard Tractor TN95FA Orchard Tractor TN95NA Orchard Tractor, Mechanical Shuttle TN95VA Eff. 01/03
